2010 MV Agusta F4 Photos

2010 MV Agusta F4 Metallic Red

2010 MV Agusta F4 Black Series

2010 MV Agusta F4 Sport Bike

2010 MV Agusta F4 Photo

2010 MV Agusta F4 Rear View

2010 MV Agusta F4 Action

2010 Suzuki GSX-R1000Z 25th Anniversary

2010 Suzuki GSX-R1000Z 25th Anniversary Picture

2010 Suzuki GSX-R1000Z 25th Anniversary Racing Wheel

2010 Suzuki GSX-R1000Z 25th Anniversary Right Wing

2010 Suzuki GSX-R1000Z 25th Anniversary Key Starter

2010 Suzuki GSX-R1000Z 25th Anniversary Exhaust

2010 Suzuki GSX-R1000Z 25th Anniversary Wallpaper

Thursday, November 26, 2009

2010 Bimota DB7R Diavolo Rosso

2010 Bimota DB7R Diavolo Rosso Image

2010 Bimota DB7R Diavolo Rosso Dash

2010 Bimota DB7R Diavolo Rosso Engine

2010 Bimota DB7R Diavolo Rosso Motor Sport

Saturday, November 21, 2009

2010 Ducati 1198R Corse Special Edition

2010 Ducati 1198R Corse Special Edition Motorcycle Wallpaper

2010 Ducati 1198R Corse Special Edition Superbike

2010 Ducati 1198R Corse Special Edition Dash

2010 Ducati 1198R Corse Special Edition Photo

2010 Ducati 1198R Corse Special Edition Rear Side View

2010 Ducati 1198R Corse Special Edition Sport Exhaust

Monday, November 16, 2009

2006 Kawasaki Ninja ZX6R/636 Customized

Vehicle Description

The fastest 600 ever produced!

2006 Kawasaki ZX6R; 636

Low Mileage

Never Crashed

Very Good to Excellent. (some boot scuffs from swinging leg over, some very light scuffs on lower belly, very hard to see...from being lowered)

Some of the fancy upgrades:

* Permanant 6" stretch; Thompsons Swingarms (best around)
* Lowered
* Erion Carbon Fiber Exhaust
* Galfer Steel Braided Brake Lines/Red
* Sportech Windscreen
* Powder Coated: Pegs/Brackets/ Levers/Bolts
* Gold DID chain

2010 Kawasaki ZX-10R Ninja

2010 Kawasaki ZX-10R Ninja SPECIFICATIONS

Engine: Liquid cooled, four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.

Capacity: 998cc

Bore x Stroke: 76 x 55 mm

Compression Ratio: 12.7:1

Induction: DFI with 43mm Keihin throttle bodies with oval sub-throttles, two injectors per cylinder

Ignition / Starting: TCBI with digital advance and Kawasaki Ignition Management System (KIMS) / electric

Max Power: 138.3 kW 188 hp@ 12500 rpm / with RAM Air 147.1 kW 200 hp @ 12500 rpm

Max Torque: 113 Nm 11.5 kgf-m @ 8700 rpm

Transmission / Drive: 6 Speed / chain

Rake / Trail: 25.5 degrees / 4.3 in.

Front Suspension: 43mm inverted fork with DLC coating, adjustable rebound and compression damping, spring preload adjustability and top-out springs

Rear Suspension: Bottom-Link Uni-Trak® with top-out spring, stepless, dual-range (high/low-speed) compression damping, stepless rebound damping, fully adjustable spring preload

Front Brakes: 2x 310mm discs 4 piston calipers

Rear Brakes: Single 220 mm disc 1 piston caliper

Front Tire: 120/70 ZR17

Rear Tire: 190/55 ZR17

Seat Height: 880 mm / 44.7 in.

Dry-Weight: 179 kg / 395 lb.

Fuel Capacity: 17 Litres / 4.5 gal

2010 Kawasaki Ninja ZX-14

2010 Kawasaki Ninja ZX-14 – USA Specifications
MSRP $13,399 to $13,699 USD

Engine: Four-stroke, liquid-cooled, DOHC, four valve per cylinder, inline-four
Displacement: 1,352cc
Bore x stroke: 84.0 x 61.0mm
Compression ratio: 12.0:1
Fuel system: DFI® with four 44mm Mikuni throttle bodies
Ignition: TCBI with Digital Advance
Transmission: Six speed
Final drive: X-Ring chain
Rake / trail: 23 degrees / 3.7 in.
Front Tire: 120/70 ZR17
Rear Tire: 190/50 ZR17
Wheelbase: 57.5 in.
Front suspension / wheel travel: 43mm inverted cartridge fork with adjustable preload, 13-way compression and 11-way rebound damping adjustment / 4.6 in.
Rear suspension / wheel travel: Bottom-Link UNI-TRAK® and gas-charged shock with adjustable preload, stepless rebound and compression damping adjustments, adjustable ride height / 4.8 in.
Front Brakes: Dual semi-floating 310 mm petal discs with dual radial-mounted four-piston calipers
Rear Brakes: Single 250mm petal disc with twin-piston caliper
Overall length: 85.4 in.
Overall width: 29.9 in.
Overall height: 46.1 in.
Ground clearance: 4.9 in.
Seat height: 31.5 in.
Curb weight: 566.7 lbs.
Fuel capacity: 5.8 gal.
Color: Candy Persimmon Red, Metallic Titanium/Metallic Spark Black
Warranty 12 months
Good Times™ Protection Plan

2009 Hero Honda Karizma ZMR

2009 Hero Honda Karizma ZMR Features:

* Sporty Under Cowl for Better Aerodynamics with more style
* Dials in Bright Yellow for Clear Daytime visibility
* Cool Key Sporting The Mark Of The Race
* Rear Shock Absorbers With A Dash Of Red
* Sleek New Muffler Cover With A Classy Chrome Finish
* Large Diameter Front Wheel Disc Brake
* Flaunt Your Power With All 223cc
* Bold New Graphics - The Art of Attracting Attention
* Stylish Visor
* Alloy Wheel Option in Fiery Red

Main Attractions:

225 cc engine
Next generation programmed Fuel Injection (PGM-Fi)
digital speedometer

Vehicle summery:

* Name: New Karizma ZMR
* Model: PGM Fi
* Type: Sports
* Top Speed: 126kph

Engine:

* Type: Air-cooled, 4-stroke single cylinder OHC
* Displacement (cc): 223 cc
* Maximum Power: 12.68 Kw (17 Ps) @ 7000 rpm
* Maximum Torque: 18.35 Nm @ 6000 rpm
* Starting: Self Start / Kick Start
* Bore x Stroke (mm): 65.5 x 66.2
* Ignition: AMI – Advanced Microprocessor Ignition System
* Compression Ratio: 9.0:1
* Carburettor: VE, Constant Vacuum Carburetor With CCVI (Carb Controlled Variable Ignition)
* Acceleration: 0 to 60 kmph in 3.8 seconds
* Maximum Speed: 125 Kmph

Transmission:

Clutch: Multiplate Wet
Gear Box: 5 speed Constant Mesh

Chassis:

Type: Tubular Single Cradle, diamond type

Dimensions:

Wheelbase (mm): 1355
Length (mm): 2125
Width (mm): 755
Height (mm): 1160
Ground Clearance (mm): 150
Kerb Weight (Kgs): 150

Suspension:

Front: Telescopic Hydraulic Shock Absorbers
Rear: Swing Arm with 5 Step Adjustable Type Hydrualic Shock Absorber

Brakes:

Front Disc: 276 mm Dia, Disc – Non Asbestoes type
Rear Drum: Internal Expanding Shoe Type (130 mm Dia); Liners – Non Asbestoes type

Wheels:

Rim Size Front: 18 x 1.85 Die Alloy Wheel
Rim Size Rear: 18 x 2.15 Die Alloy Wheel

Tyres:

Front: 2.75 x 18 – 42 P
Rear: 100/90 x 18 – 56 P

Electricals:

* Battery: 12V – 7 ah
* Alternator: 188 W
* Spark Plug: NGK-DPR 8 EA 9, Champion PRA 7 HC
* Head Lamp: 35W / 35W – Halogen Bulb (Multi-Reflector – D.C Type)
* Tail Lamp / Stop Lamp: 5 / 21 W x 2 Nos. (Multi-Reflector)
* Number Plate: 5 W
* Turn Signal Lamp: 21W x 4 nos (Multi – Reflector)
* Fuse: 20 Amps. 15 Amps , 7.5 Amps

Fuel:

Tank Capacity: 15 Ltrs
Reserve: 2 Ltrs

2010 Kawasaki Ninja 250R

2010 Kawasaki Ninja 250R – USA Specifications

MSRP $4,299 USD

Engine: Four-stroke, liquid-cooled, DOHC, parallel twin

Displacement: 249cc

Bore x stroke: 62.0 x 41.2mm

Compression ratio: 11.6:1

Cooling: Liquid

Carburetion: Keihin CVK30 x 2

Ignition: Digital

Transmission: Six-speed

Final drive: O-ring chain

Frame: Semi-double cradle, high-tensile steel

Wheelbase: 55.1 in.

Rake / trail: 26 degrees / 3.2 in.

Front suspension / wheel travel: 37mm hydraulic telescopic fork / 4.7 in.

Rear suspension / wheel travel: Bottom-Link UNI-TRAK® with 5-way adjustable preload / 5.1 in.

Front tire: 110/70-17

Rear tire: 130/70-17

Front brake: Single 290mm hydraulic petal disc with two-piston caliper

Rear brake: Single 220mm petal disc with two-piston caliper

Overall length: 82.1 in.

Overall width: 28.1 in.

Overall height: 43.7 in.

Seat height: 30.5 in.

Curb weight: 374.9 lbs.

Fuel capacity: 4.8 gal.

Color choices: Metallic Island Blue, Passion Red, Lime Green/Pearl Stardust White, Ebony/Candy Persimmon Red

Warranty 12 months
Good Times™ Protection Plan 12, 24, 36 or 48 months

2010 Kawasaki Ninja 650R Review

2010 Kawasaki Ninja 650R Blue Color

2010 Kawasaki Ninja 650R Black Color

2010 Kawasaki Ninja 650R Spec :

MSRP $7,099 USD

Engine: Four-stroke, liquid-cooled, DOHC, four-valve per cylinder, parallel twin

Displacement: 649cc

Bore x stroke: 83.0 x 60.0mm

Compression ratio: 11.3:1

Cooling: Liquid

Fuel injection: Digital fuel injection with two 38mm Keihin throttle bodies

Ignition: Digital CDI

Transmission: Six-speed

Final drive: O-ring chain

Frame: Semi-double cradle, high-tensile steel

Rake / trail: 25 degrees / 4.2 in.

Wheelbase: 55.5 in.

Front suspension / wheel travel: 41mm hydraulic telescopic fork / 4.7 in.

Rear suspension / wheel travel: Single offset laydown shock with adjustable spring preload / 4.9 in.

Front tire: 120/70×17

Rear tire: 160/60×17

Front brake: Dual 300mm petal discs with two-piston calipers

Rear brake: Single 220mm petal disc with single piston caliper

Overall length: 82.7 in.

Overall width: 29.9 in.

Overall height: 47.2 in.

Seat height: 31.1 in.

Curb weight: 449.8 lbs.

Fuel capacity: 4.1 gal.

Colors: Candy Lime Green, Ebony, Metallic Island Blue
Good Times™ Protection Plan 12, 24, 36 or 48 months

Note: Specifications and pricing are subject to change

2010 Kawasaki Ninja ZX6R Picture and Specification

One of the arch auto aggregation in the apple Kawasaki is actuality in India to barrage its exceptional bike The Kawasaki NINJA ZX-6R in the year of 2010. It is a new apparatus in aloof about every way. The administration is acutely changed, but alike added chiefly the achievement and engineering has been overhauled and absolutely reworked to accommodate an absurd benumbed experience. TheKawasaki Ninja ZX-6R is a Kawasaki middleweight action bike. It was alien in 1995 and has been consistently adapted throughout the years in acknowledgment to new articles from rivals companies. It has a 599cc engine. It's comes with 6 automated accessory box. It has a New bacteria anatomy with a above abridgement in weight and bigger ability commitment action added absolute control, lighter administration and bigger acceleration. The new failing sub-frame is actual narrow, for a bunched and abbreviate rear end. New rear sub-frame is narrower, authoritative it easier to ability the ground.

2010 Kawasaki Ninja ZX-6R – USA Specifications

MSRP $10,499 USD

ENGINE

Engine: Four-stroke, liquid-cooled, DOHC, four valves per cylinder, inline-four

Displacement: 599cc

Bore x stroke: 67.0 x 42.5mm

Compression ratio: 13.3:1

Fuel injection: DFI® with four 38mm Keihin throttle bodies, oval sub-throttles, two injectors per throttle body

Ignition: TCBI with digital advance

Transmission: Six speed

CHASSIS

Final drive: X-ring chain

Rake / trail: 24 deg / 4.1 in.

Frame type: Aluminum perimeter

Front tire: 120/70 ZR17

Rear tire: 180/55 ZR17

Wheelbase: 55.1 in.

SUSPENTION

Front suspension / wheel travel: 41 mm inverted Showa Big Piston Front fork with top-out springs, stepless compression and rebound damping, fully-adjustable spring preload / 4.7 in.

Rear suspension / wheel travel: Bottom-Link Uni-Trak® with gas-charged shock, top-out spring and pillow ball upper mount, dual-range (high/low-speed) stepless compression damping, 25-way adjustable rebound damping, fully-adjustable spring preload / 5.3 in.

Front brakes: Dual 300mm petal rotors with dual radial-mounted, four-piston, four-pad calipers

Rear brake: Single 220mm petal rotor with single-piston caliper

Overall length: 82.3 in.

Overall width: 28.0 in.

Overall height: 43.9 in.

Fuel capacity: 4.5 gal.

Seat height: 32.1 in.

Curb weight: 421.2 lbs.

Warranty: 12 Months
Good Times™ Protection Plan 12, 24, 36 or 48 months

Modifikasi Fairing Bajaj Pulsar

Bajaj Pulsar Make Fairing Ninja 250 CC

Bajaj Pulsar uses fairing kawasaki ninja 250, appears the question of how to install. This fairing installation with a custom modification to the workshop.
